Number of channels – While you may only want to look at one signal at a time, having more than one channel carries some significant potential benefits. The place to begin is understanding the oscilloscope’s key specifications and features and evaluating them against your specific needs. Choosing among the USB oscilloscope options has thus become much more complex.Įntry-level USB oscilloscopes such as the DPScope-II are suitable for modest signal requirements such as audio and serial buses. Devices are on the market today that run the gamut from $20 to $20,000, with performance ranges equally widespread but not necessarily correlated.
For the examination of signals that fell within the limited range that these first USB oscilloscopes could handle, they provided an interesting alternative to a more traditional (and expensive) oscilloscope.įast forward to today and you’ll find that USB oscilloscopes need no longer be low-performance or low-cost. Early devices were both crude and had limited performance but had the advantage of being relatively inexpensive. It wasn’t long after the Universal Serial Bus (USB) became available that someone figured out how to use the bus to power and attach a digitizer whose data the computer could use to emulate the operation of a traditional oscilloscope. Understanding the key specifications can help in making the right decision. The cost and size advantages of such USB oscilloscopes make them a tempting addition to the developer’s toolkit, but they are now available in a bewildering range of performance and price points. One of the more recent innovations was stripping down the instrument to a signal acquisition front end that connects to a personal computer through the USB, using the PC’s resources to eliminate the bulk and cost of a power supply and display. Oscilloscopes are one of the fundamental pieces of test equipment that an electronics developer can have, and they have been in use for more than 50 years.
